It has flawless switching operations or dimming + switching, when used in combination with 0-10V dimmable LED drivers. It has a host of settings that can be changed by using the DIP switch set inside or the optional WEC-3RC Remote Control.
- Voltage: 120/277 VAC, 50/60Hz
- Detection Zone: 9.8Ft. ~ 32.8Ft. (Adjustable)
- Remote Range: 30Ft. (9M)
- Hold Time: 10S. - 30Min. (Adjustable)
- Daylight Sensor: 10 - 2000Lux (Adjustable)
- Dimming Control: 0-10V Dimming
- Detection Angle: 360° (Ceiling Mounted)
