Greengate OAC-DT-0501-R MicroSet Dual Tech Low Voltage Ceiling Sensor, 500 sq. ft.

GreengateSKU: OAC-DT-0501-R

In stock


The Dual Technology sensor’s combination of Ultrasonic and Passive Infrared technologies offers the most complete sensing equipment available today. MicroSet self- adjusting Dual Technology sensors drastically simplify and reduce a contractor’s installation and adjustment time period.


  • Color: White
  • Technology: Passive Infrared (PIR) and Ultrasonic (US)
  • Voltage: 10-30 VDC from Greengate Switchpack or Greengate system
  • Coverage: 500 sq. ft.
  • Field of View: One Way (180°)
  • Housing: Durable, injection molded housing
  • Mounting: Mounts directly to ceiling tile, to a 4” square box and round mud ring or to 4” octagon box
  • MicroSet self-adjusting Time Delay and sensitivity
  • Built-in light level sensor
  • Units available for control of single or two separate loads
  • Selectable Walk-Through Mode
  • Dual Relay control
  • Includes BAS Relay & Daylight Sensor
