WaveLinx WSP-CA-010 PRO Universal Dimming Switchpack with Dry Contact Input
SKU WSP-CA-010
Original price
$0.00
-
Original price
$0.00
Original price
$472.61
$472.61
-
$472.61
Current price
$472.61
Availability:
in stock, ready to be shipped
Estimated Shipping Widget will be displayed here!
OVERVIEW
The WaveLinx PRO Emergency Switchpack (ESP-P-010-347) is a lighting control device designed to control (on/off/dim) commercial and industrial lights while providing Emergency capabilities without additional hardware.
Features
- Voltage: 120-347V
- Relay control of loads up to 20amps (including receptacles)
- 0-10V dimming control of up to 15 typical ballasts / LED drivers
- Plenum rated
- Fails safe to 100% if communications are lost
- Energy calculations available through WaveLinx CORE based on max load input
- Greengate low-voltage sensor integration or contact closure input
Dimensions
- Length: 3.5"
- Width: 2.7"
- Height: 1.6"
Documents
Labels and Listings
- cULus Listed - Energy Management Equipment (UL916)
- RoHS Compliant
- Meets latest CEC Title 24 requirements
